MicroScribe Utility Software

(MUS) 7.1

*** Compatible with all MicroScribe arm models ***

What is MUS 7.1?

Revware's MicroScribe Utility Software™ (MUS) 7.1 is a stand-alone utility that runs alongside other Microsoft Windows programs and connects your MicroScribe Portable CMM to many third-party software platforms.

MUS provides the pipeline for 2D and 3D data to be sent from your MicroScribe PCMM to host applications that do not contain native support for MicroScribe arms.

A variety of data output formats can be configured inside of MUS, and more output types are now available in MUS 7.1.  If your application supports command line or dialog entry of 3D coordinates, this utility can be easily made to work with your application.

Best of all, MUS 7.1 is backwards-compatible for use with all MicroScribe 3D digitizers!

mus-7-1-home-with-toolbar

Better help means better workflow.  MUS 7.1 now contains an expanded web-based help system that functions online or offline.

New Intuitive Help

The new HTML help system in MUS 7.1 offers a responsive and intuitive navigation

Expanded MicroScribe help topics give detailed, user-friendly instructions

Seamless integration of multimedia elements makes finding the information you need quick and easy

Framework and Security Updates



Latest improvements to the internal architecture of MUS 7.1 include updates to the Windows framework to maintain robust security while optimizing performance on your system.

Best-Red-1024x576
Tile-Format_String_Create

Other New Features

Updated format string support for applications such as Fusion 360®, SOLIDWORKS®, KeyCreator® and more

Additional settings for assigning secondary button functionality on a multi-button input device

Advanced feature Joint Data Mode allows you to see output from your MicroScribe arm joint-by-joint

Accuracy is Critical

The Single Point Articulation Test, or SPAT, is a ten-point repeatability test used in combination with MUS to help determine the accuracy of your MicroScribe Portable CMM arm. SPAT testing can help show whether your device demonstrates data repeatability (results can vary based on the technique of the user).

Revware's SPAT is based on the ASME B89.4.22 Methods for Performance Evaluation of Articulated Arm Coordinate Measuring Machines. The SPAT is applied in the assessment of MicroScribe digitizers at various stages of manufacture and repair.

Tile-Assessing_Accuracy

By using the SPAT template provided with MUS 7, you can perform a simple test on your MicroScribe arm.
